Industrial Flow Meters
Leading Manufacturers, Exporters, Wholesaler of Electromagnetic Flow Meter, Magnetic Flow Meter, Turbine Flow Meter and Ultrasonic Flow Meter from Pune.
MOQ : 1 Piece
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Electronet |
| Material | Aluminum |
| Finishing | Powder Coated |
| Driven Type | Electric |
| Color | Blue |
| Power | 24VDC Or 220VAC |
| Pressure | Medium Pressure |
| Operating Type | Automatic |
| Usage | Industrial, Chemical Flow Measurement, Water And Chemicals |
| Voltage | 220V |
| Operating Temperature | 0 To 80 Digree |
| Packaging Type | Carton Box, Wooden Box |
| Certificate | ISO 9001:2008 Certified |
| Line Size | 25 Mm To 1000mm |
| Specialities | Accuracy |
| Type | Electromagnetic Flow meter |
| Frequency | 50-60 Hz |
| Accuracy | < ± 0.5% Of M.V. +(± 5mm /sec) For Velocity Range 0.3 M/s To 6 Or 12 M/s |
| Country of Origin | India |
| Display | Digital |
| Warrenty | 2 Years |
| Corrosion Resistance | Yes |
| Repeatability | +/- 0.2% Of M.V. |
Preferred Buyer From
| Location | Worldwide |
Eectronet series ELMAG -200 are micro-controller based full bore type electromagnetic flow meters specially used for various industrial applications. These flow meters accurately measure the flow rate of conductive liquids and slurries in closed pipes. Due to its simple and rigid design, the flow meter is an obstruction less and maintenance-free instrument in place of conventional mechanical flow measuring devices. The use of ‘Pulsed DC’ technology offers highest ability and better measuring accuracy in the form of electrical signal 4-20 mA DC linearly proportional to volumetric flow. The instrument is based on Faraday’s law of electromagnetic induction. A magnetic ?eld is generated by the instrument in the flow tube. The fluid flowing through this magnetic field generates a voltage that is proportional to the flow velocity. Corresponding electrical output is provided with respect to measuring flow range.
Key Features;
Universal Power Supply 90 to 250V AC / 24V DC / Solar Powered
Suitable for conductive liquids
Full bore type
Empty pipe indication
Material of construction in accordance to process parameters
Local Indication through LCD Display
Inbuilt Relay Status output (High / Low / Batch)
HART Compatible
Optional pressure measurement along with flow
MOQ : 1 Piece
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | ELECTRONET |
| Material | Aluminum |
| Driven Type | Battery |
| Color | Blue |
| Automatic Grade | Fully Automatic |
| Power Supply | Battery Powered |
| Application | Industrial |
| Size | Multisizes |
| Feature | Accuracy |
| Certificate | CE Certified, ISO 9001:2008 |
| Type | Magnetic Flow Meter |
| Accuracy | < ± 1% Of M.V. +(± 5mm /sec) For Velocity Range 0.3 M/s To 6 Or 12 M/s |
| Country of Origin | India |
| Display | Local, Remote |
| Output | 4mA To 20 MA |
| Warrenty | 5 Years |
Preferred Buyer From
| Location | Worldwide |
Electronet series ELMAG -600 battery-powered Electromagnetic flow meter. It is ideal when power supply on field is not present, the battery powered ELMAG -600 gives the flexibility to install a reliable flow meter, virtually anywhere, without distorting accuracy & performance. ELMAG -600 is provided with 2 to 10 years of continuous battery operation based on sampling time & communication interval. The flow meter is extremely easy to use, simple to install & requires no regular maintenance. The product is engineered for various industrial as well as domestic applications such as Municipal and Industrial Water applications, Cooling tower, Water treatment, etc. The LCD display provides indication for flow rate & totalized flow with key selection. The display automatically turns OFF after 10 minutes, which can be again turned ON by pressing the 'enter' key.
Key Features;
Battery / Solar Powered
Suitable for conductive liquids
Full bore type
Empty pipe indication
Data Logging facility
Local Indication through LCD
Communication port (Optional)
Simple & Cost Effective Construction
Maintenance Free
MOQ : 1 Piece
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Electronet |
| Material | Stainless Steel |
| Finishing | Powder Coated |
| Driven Type | Electric |
| Power | 24VDC Or 220VAC |
| Pressure | Medium Pressure |
| Operating Type | Automatic |
| Usage | Industrial, Chemical Flow Measurement, Water And Chemicals |
| Model Number | FL-100 |
| Voltage | 220V |
| Operating Temperature | -20 DegC To 75 DegC |
| Packaging Type | Carton Box, Wooden Box |
| Certificate | ISO 9001:2008 Certified |
| Line Size | 15-200NB |
| Specialities | Accuracy |
| Type | Turbine Flow Meter |
| Accuracy | < ± 0.5% Of F. S. ± 5mm /sec For Velocity Range 0.3 M/s To 6 Or 12 M/s |
| Country of Origin | India |
| Display | Digital |
| Output | 4-20 MA |
| Warrenty | 2 Years |
| Item Code | FL-100 |
Preferred Buyer From
| Location | Worldwide |
Electronet series FL-100 are 2 wire turbine flow transmitters specially used for various industrial applications. The flowing media engages a vaned rotor causing it to rotate at an angular velocity proportional to flow rate. The pick-up coil senses the spinning motion of the rotor inside the pipe & converts it into a pulsating electrical signal. Summation of the pulsating spinning motion of the rotor inside the pipe & converts it into a pulsating electrical signal. Summation of the pulsating electrical signal is directly related to the total flow. The frequency is linearly proportional to flow rate which is converted to electrical signal 4 - 20 mA .
Key Features;
2 Wire System
Simple & Cost Effective Construction
Local LCD Display
Suitable for Conductive and Non-Conductive Liquids
Electronics Protection Class : Weatherproof IP 65, IP 67
Easy Maintenance
MOQ : 1 Piece
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | Electronet |
| Material | Stainless Steel |
| Finishing | Powder Coated |
| Driven Type | Electric |
| Color | Grey |
| Power | 24VDC Or 220VAC |
| Operating Type | Automatic |
| Usage | Industrial, Chemical Flow Measurement, Water And Chemicals |
| Voltage | 220V |
| Packaging Type | Carton Box, Wooden Box |
| Certificate | ISO 9001:2008 Certified |
| Line Size | 15-600mm |
| Specialities | Accuracy |
| Type | Ultrasonic Flow Meter |
| Accuracy | < ± 0.5% Of M.V. ± 5mm /sec For Velocity Range 0.3 M/s To 6 Or 12 M/s |
| Country of Origin | India |
| Display | Digital |
| Storage Temperature | -20 DegC To 85 DegC |
| Warrenty | 2 Years |
| Electronics Enclosure | Aluminium Diecast Or SS |
Preferred Buyer From
| Location | Worldwide |
Electronet series ASIONIC -400 Ultrasonic flow meters give the flexibility to install a reliable flow meter, virtually anywhere without distorting accuracy and performance. The flow meter is extremely easy to use, simple to install and requires no regular maintenance. The product is engineered for various industrial as well as domestic applications such as Municipal and Industrial Water applications, Cooling tower, Water treatment, etc. The LCD display provides indication for flow rate and totalized flow with key selection. The display auto shuts off after 10 minutes, which increases the battery life in case of battery powered flow meter. The display can be turned ON by pressing the 'enter' key.
Ultrasonic Measurement using Transit Time Technology
Full Bore Type
Local Indication through LCD Display
Simple and Cost Effective Construction
Empty Pipe Indication
Automatic Meter Reading option over GSM, GPRS & RF
Electronic Protection Class : Field Mount Weather Proof IP-67, DIN Standard (IP 54), Flameproof (CMRI IIA IIB Certified)
Leak, Burst and Tamper Detection
No Pressure Drop
