TS2000 TT Temperature Transmitter Switch

Industrial Temperature Transmitter Key Features

• Single sensor input for flexible measurement applications

• Durable SS-316 enclosure for superior corrosion resistance

• IP-68 protection for reliable performance in harsh and wet environments

• Switch functionality for versatile control and monitoring

• Optional RS-485 (MODBUS RTU) communication for seamless system integration and remote access

  Technical Specifications Performance Characteristics

• Type of Input: RTD (PT-100 / PT-200)

• Type of Output: 4–20 mA

• Alarm / Relay Output: 1 Relay Output (Optional)

• Communication: RS-485 MODBUS RTU (Optional)

• Display: Backlight LCD

• Isolation: 1.4 kV between Input, Output & Power Supply

• Accuracy: ±0.1% FS

• Repeatability: ±0.1%

• Linearity: ±0.05% of Full Scale

• Stability: ±0.2% of URL per year

• Response Time: 1 second

• Temperature Coefficient: ±0.01% per °C

• Power Supply Effect: < ±0.005% of Span

Electrical & Power

• Power Supply: 18–36 V DC

• Power Consumption: <5 W

• Reverse Polarity Protection: Provided

• Surge Protection: In-built

Construction & Protection

• Material (MOC): SS-316

• Electronics Enclosure: SS-316

• Protection Class: Weatherproof IP-68

• Electrical Connection: M12 Connector

Calibration & Diagnostics

• Calibration: Software-based calibration

• Self-Diagnosis: Sensor open indicator

• Isolation: 1.4 kV input/output/power isolation

Environmental Conditions

• Ambient Temperature: -20°C to 75°C

• Ambient Humidity: 5% to 95% RH (non-condensing)

Mounting & Weight

• Mounting Options: Pipe mount / Wall mount

• Weight: Less than 3 kg
