Product Details
ELMAG-200 – Full Bore Electromagnetic Flow Meter Features
Universal power supply: 90–250V AC / 24V DC / Solar Powered
Suitable for conductive liquids
Full-bore design
Empty pipe indication
Material of construction selected as per process requirements
Local indication through LCD display
Inbuilt relay status output (High / Low / Batch)
HART compatible
Optional inbuilt pressure measurement
Optional flow + pressure combined measurement
Description
Electronet Series ELMAG®-200 is a microcontroller-based, full-bore electromagnetic flow meter ideal for precise flow measurement of conductive liquids and slurries in closed pipes.
Its obstruction-less design and absence of moving parts make it a maintenance-free alternative to conventional mechanical meters.
Using advanced Pulsed DC excitation, the meter provides superior accuracy and stability, delivering a 4–20 mA DC output proportional to volumetric flow rate.
Based on Faraday’s Law of Electromagnetic Induction, the flow meter measures flow by detecting the voltage generated when conductive fluid passes through a magnetic field inside the measuring tube.
The ELMAG-200 is available in various configurations to suit diverse industrial requirements including optional pressure measurement.
Technical Specifications Process & Media
Media: Conductive liquid
Minimum Conductivity: > 5 µS/cm
Viscosity: Up to 200 cP
Line Size: 15 NB to 1000 NB
Excitation: Pulsed DC
Outputs (Selectable)
Output 1:
4–20 mA DC
4–20 mA DC with HART (Generic)
Output 2:
Pulse Output (Open Collector Type)
Output 3:
2 Relay Outputs
Communication Options:
RS485 (MODBUS RTU)
GSM / GPRS (Dual SIM)
Ethernet (MODBUS TCP)
Display
LCD Display
6-digit flow rate
8-digit totalizer
Performance Specifications Velocity
0.3 m/s – 2.5 m/s (up to maximum 10 m/s)
Engineering Units
User programmable (Default: m³/hr)
Calibration
Wet calibrated at IEC / ISO / EN17025 NABL Accredited Facility
Accuracy
< ±0.5% of Measured Value
(+5 mm/sec for velocity range 0.3 to 6 or 12 m/s)
Linearity
±0.5% of Measured Value
Repeatability
±0.2% of Measured Value
Temperature Coefficient
±0.05% per °C
Process Conditions Process Temperature
–20 to 85°C (Rubber Lining)
–20 to 220°C (PTFE / PFA Lining)
Process Pressure
Up to 16 kg/cm² (Higher on request)
Material of Construction
Lining: Neoprene / Ebonite Rubber / PTFE / PFA / PU / Ceramic
Flange: MS / CS / SS316 / SS304
Electrodes: SS316L / Hastelloy-C / Platinum / Tantalum / Titanium
Coil Housing: SS304
Electrical & Electronics Power Supply
Option 1: 90–250V AC, 50Hz
Option 2: 24V DC (±10%)
Power Consumption
< 10 VA
Inline Pressure Sensor (Optional)
16 kg/cm²
Isolation
1.4 kV between input, output & power supply
Response Time
< 1 second
Enclosure Options
Field Mount Weatherproof IP-67 / IP-68 (NEMA 6 / 6P)
DIN Standard IP-54 (NEMA 3)
Flameproof: CMRI IIA IIB Certified, ATEX Ex-d
Sensor / Flow Tube Protection
Weatherproof IP-67 / IP-68
Installation Process Connections
ANSI 150 Flanged (ASME B16.5)
Other standards on request
Mounting
In-line horizontal or vertical installation
Ambient Conditions
Temperature: –20 to 70°C
Humidity: 5% to 95% (Non-condensing)
