10 Piece (MOQ)
| Business Type | Manufacturer, Exporter, Supplier |
| Product PDF |  View |
| Repeatability | ±0.5% Of F.S. |
| Line Size | 200 NB To 3000 NB |
| Click to view more | |
Product Details
ELMAG-100 – Insertion Type Electromagnetic Flow Meter Features
Insertion type design
Suitable for conductive liquids
Material of construction selected as per process requirements
Local indication through LCD display
Universal power supply: 90 to 250V AC (Optional: 24V DC)
Simple and cost-effective construction
Programmable engineering unit conversion
Communication port available
Inbuilt relay status output (High / Low / Batch)
Description
Electronet Series ELMAG-100 is a microcontroller-based insertion type Electromagnetic Flow Meter designed for accurate flow measurement of conductive liquids and slurries in closed pipelines.
The flow meter features an obstruction-free measuring design, making it maintenance-free compared to conventional mechanical meters.
Using advanced Pulsed DC excitation, the flow meter ensures highly stable and accurate flow measurement and provides a 4–20 mA DC electrical output linearly proportional to volumetric flow rate.
Based on Faraday’s Law of Electromagnetic Induction, the meter generates a magnetic field inside the flow tube. The conductive fluid passing through it induces a voltage proportional to the flow velocity, which is then converted into a corresponding electrical signal.
The ELMAG-100 is available in Hot Retractable and Fixed Insertion versions to suit a wide range of industrial applications.
Technical Specifications Model Types
Mains Operated / 24V DC
Two-Wire Version
Battery Operated
Media
Conductive liquids
Conductivity: > 5 µS/cm
Viscosity: Up to 200 cP
Line Size
200 NB to 3000 NB
Excitation
Pulsed DC
Display
LCD Display
6-digit flow rate
8-digit totalizer
4-digit pressure
Calibration Range
As per application requirement
Accuracy
< ±1% of E.S.
Additional: ±5 mm/sec for velocity range 0.5 m/s to 6 or 12 m/s
Linearity
±1% of F.S.
Repeatability
±0.5% of F.S.
Temperature Coefficient
±0.05% per °C
