PH 100S ORP Transmitter

PH 100S ORP Transmitter

Link Copied

10 Piece (MOQ)

Edit
Get Best Price
Business Type Manufacturer, Exporter, Supplier
Product PDF View
Type ORP Transmitter
Application Industrial
Click to view more
Request to Call Send Enquiry

Product Details

Power Supply
24V DC, two-wire loop powered
Power Consumption
< 50 mW
Dimensions
155 mm (H) × 105 mm (W) × 130 mm (D)
Output
4-20mA
Temperature Range
0-100°C
Display
LCD
Protection Class
Weatherproof IP-67
pH 100S – pH / ORP Transmitter
Description

Electronet Series pH-100S is an industrial-grade pH / ORP transmitter designed for accurate and continuous online measurement. It accepts input from any standard pH or ORP electrode, making it compatible with all major electrode brands.
The transmitter converts the signal into a standard 4–20 mA output (with optional HART). An LCD display provides real-time pH / ORP indication, while Zero/Span adjustments are easily accessible. Its user-friendly pictograph interface and rugged construction make it suitable for demanding industrial environments.


Features


  • Online pH / ORP measurement




  • 2-wire loop-powered system




  • 4–20 mA DC output / 4–20 mA with HART (Generic)




  • Auto / manual temperature compensation




  • Clear LCD display for on-line indication




  • Simple interface with intuitive pictographs




  • Easy installation




  • Compatible with any make of pH / ORP electrode





Technical Specifications
Input


  • Type: pH / ORP Electrode (compatible with any make)




Output


  • Signal: 4–20 mA / 4–20 mA with HART (Generic)




  • Accuracy:




    • pH: ±0.05 pH




    • ORP: ±3 mV






  • Repeatability: ±0.05% of span at 25°C




  • Response Time: < 1000 mSec




  • Temperature Coefficient: ±0.05% per °C




Display


  • Type: LCD Display




  • Range:




    • pH: 0 to 14 pH




    • ORP: ±2000 mV






Calibration


  • Method: 3-point buffer calibration




Temperature Compensation


  • Sensor: RTD PT-100 / PT-1000




Electrical

  • Power Supply: 24V DC, two-wire loop powered


  • Power Consumption: < 50 mW




  • Isolation: 1.4 kV between input, output & power




Physical


  • Dimensions: 155 mm (H) × 105 mm (W) × 130 mm (D)




  • Mounting: 2" pipe mounting




  • Housing: Cast aluminum with epoxy coating (NEMA 4X) / SS316




  • Protection Class: Flameproof CMRI IIA IIB / Weatherproof IP-67




  • Weight: Approx. 1 kg




Connections


  • Sensor Connection:




    1. BNC Connector




    2. Terminal connection





  • Conduit Entry:




    1. M20 × 1.5 (F)




    2. ½" NPT (F)





Optional






  • Flow-through assembly: SS316 / PP
