DO 100S Digital Dissolved Oxygen Transmitter

Link Copied

10 Piece (MOQ)

Edit

Business Type	Manufacturer, Exporter, Supplier
Product PDF	View
Type	Dissolved Oxygen Transmitter
Input Type	From DO Electrode
Click to view more

Product Details

output signal

4–20 MA DC / 4–20 MA With HART (Generic)

Transmitter Accuracy

±0.25% F.S.

Repeatability

±0.05% Of Span At 25°C

Response Time

< 1000 MSec

Display Type

LCD Display

Calibration Range

0 To 20.9 Ppm

Power Supply

24V DC, Two-wire Loop Powered

Power Consumption

< 50 MW

Isolation

1.4 KV Between Input, Output & Supply

Temperature Compensation

RTD PT-100 / PT-1000

Temperature Coefficient

±0.01% Per °C

Ambient Conditions

–20°C To 70°C / 5–95% RH

Dimensions

155 Mm (H) × 105 Mm (W) × 130 Mm (D)

Mounting

2” Pipe Mounting

Housing

Cast Aluminum With Epoxy Coating (NEMA 4X) / SS316

Protection Class

Flameproof CMRI IIA IIB / Weatherproof IP-67

Sensor Connection

BNC Connector, Terminal Connection

Electrical Conduit Entry

M20 × 1.5 (F), ½

DO 100S – Dissolved Oxygen Transmitter
Description

Electronet Series DO 100S is a high-performance Dissolved Oxygen Transmitter designed for reliable and continuous online measurement in industrial applications. It accepts input from a DO electrode and converts the signal into a standard 4–20 mA output (optional HART).
The transmitter includes an LCD display for real-time indication, while Zero/Span adjustments are easily accessible for quick calibration. Its rugged construction and user-friendly interface make it suitable for demanding process environments.
